Manufacturer's Part Number: 13420
Inductive Sensor. Ident. no.: 13420. 2 cable entries (axial, radial). Threaded barrel, M30 x 1.5. Plastic, ABS. AC 2-wire, 20
250 VAC. DC 2-wire, 10
300 VDC. Programmable connection (NC or NO). Terminal chamber
- Design:
- Threaded barrel
- Construction size:
- M30 x 1.5
- Rated switching distance:
- 10 mm
- Mounting:
- Flush
- Operating voltage:
- 20?à250 VAC / 10?à300 VDC
- Output function:
- Connection programmable, 2-wire
- Switching frequency:
- 0.020 kHz
- Electrical connection:
- Terminal chamber
- Housing material:
- Plastic, ABS
- Ambient temperature:
- -25?à+70 ??C
- Protection class:
- IP67
- Catalog:
- View
- Datasheet:
- View
