Turck Bi5-Em18Wd-Ap6X/S929 Inductive 4614902
Turck
$349.70
Manufacturer's Part Number: 4614902
Inductive Sensor. For Harsh Environments and Temperatures up to -60 °C. Ident. no.: 4614902. Threaded barrel, M18 x 1. Stainless steel, 1.4571. Protection class IP68/IP69K. For temperatures up to -60 °C. PTFE front cap. Resistant to cleaning agents. Resistance to cooling lubricants, cutting and grinding oils. Suitable for applications in the food industry. DC 3-wire, 10
30 VDC. NO contact, PNP output. Cable connection
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 5 mm
- Mounting:
- Flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, PNP
- Switching frequency:
- 1.0 kHz
- Electrical connection:
- Cable
- Cable length (L):
- 2.0 m
- Housing material:
- Stainless steel, 1.4571 (AISI 316Ti)
- Ambient temperature:
- -60?à+60 ??C
- Protection class:
- IP68/IP69K
- Special features:
- Wash down, Pressure resistant
- Quick Start Guide:
- View
- Catalog:
- View
- Datasheet:
- View
