Turck EKRT-A4.220-ESWT-A4.210-DC2K-8 ID# 200001422
Turck
$75.60
Manufacturer's Part Number: 200001422
Actuator and Sensor Cable. Extension Cable. Ident. no.: 200001422. M12, Female, Straight, 2-pin, Torque sleeve. M12, Male, Right angle, 2-pin,Torque sleeve. Instrumentation Tray Cable. Black PVC jacket, shielded, 3X22 AWG. Sunlight Resistant. -40 Cold Bend Rating. Oil Resistant. Flame Ratings: UL 1685 FT4, UL1061, CSA FT4
- Application:
- Signal
- Design:
- Double-ended
- Connector A:
- Female, M12 ?ù 1, Straight, A-code
- Connector B:
- Male, M12 ?ù 1, Right angle, A-code
- Current:
- 4 A
- Cable diameter:
- ?ÿ 5.13 mm
- Length (L):
- 8.0 m
- Cable jacket:
- PVC, Black
- Number of Conductors:
- 3
- Protection class (When coupled):
- IP67, IP68, IP69, IP69K
- Special Features:
- Torque sleeve
- Approvals:
- UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
