Manufacturer's Part Number: 7540040
Trip amplifier. 1-channel. Ident. no.: 7540040. Monitors 3 limit values at a current or voltage input. Power supply of 2-wire or 3-wire transmitters/sensors. Input circuit: 0/4
20 mA; 0/2
10 V. Output circuit: 3 independent limit value relays. Limit value relay adjusted via rotary coding switches. Hysteresis and relay outputs adjusted via DIP switch. Universal operating voltage. Complete galvanic isolation. Input reverse-polarity protected. CFMUS, TR CU
- Signal type:
- Analog input
- Device type:
- Trip amplifier
- Ex version:
- no
- Approvals:
- cFMus, TR CU
- Nominal voltage:
- Wide voltage range
- Number of channels:
- 1
- Digital output:
- Relay output
- Electrical connection:
- 4 ?ù 5-pin removable terminal blocks, reverse polarity protected, screw terminal
- Protection class:
- IP20
- Product series:
- IM
- Quick Start Guide:
- View
- Flyer:
- View
- Datasheet:
- View
