Turck

Turck Pkg 3Z-0.4-Psg 3 Cordsets U2134-89

(No reviews yet) Write a Review
SKU:
PKG 3Z-0.4-PSG 3
MPN:
U2134-89
Condition:
New
Application:
Signal
Design:
Double-ended
Connector A:
Female, M8 - Ø 8 mm (snap), Straight
Connector B:
Male, M8 - Ø 8 mm (snap), Straight
Coupling nut:
Plastic
Voltage:
125 V
Current:
4 A
Cable diameter:
Ø 4.39 mm
Length (L):
0.40 m
Cable jacket:
PVC, Yellow
Number of Conductors:
3
Protection class (When coupled):
IP67
Approvals:
UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
  • Turck Pkg 3Z-0.4-Psg 3 Cordsets U2134-89
  • Turck Pkg 3Z-0.4-Psg 3 Actuator and Sensor Cable, Extension Cable
$26.50

Description

Actuator and Sensor Cable. Extension Cable. Ident. no.: U2134-89. Straight Female M8 snap-on picofast Connector. Straight Male M8 snap-on picofast Connector. M8, Female, Straight, 3-pin. Snap-on Connector with Sleeve Lock. M8, Male, Straight, 3-pin. Snap-on Connector. General Purpose Cable. Yellow PVC jacket, 3X24 AWG. -40 Cold Bend Rating. Flame Ratings: UL1061, CSA FT1. Flexlife® and C-Track Approved
