Turck Pkw 3Z-P7X2-2/S760 Cordsets 100036793
Turck
$37.80
Manufacturer's Part Number: 100036793
Actuator and Sensor Cable. Connection Cable. Ident. no.: 100036793. M8, Female, Right-angle, 3-pin. Snap-on Connector with Sleeve Lock. With 2-color LED (PNP, yellow, green). General Purpose Cable. Black PVC jacket, 3X24 AWG. -40 Cold Bend Rating. Flame Ratings: UL1061, CSA FT1. Flexlife® and C-Track Approved
- Application:
- Signal
- Design:
- Single-ended
- Connector A:
- Female, M8 - ?ÿ 8 mm (snap), Right angle
- Number of contacts:
- 3
- Connector body:
- Plastic, TPU, Translucent
- Signal Indicator:
- LED, Yellow
- Current:
- 4 A
- Cable diameter:
- ?ÿ 4.19 mm
- Length (L):
- 2.0 m
- Cable jacket:
- PVC, Black
- Number of Conductors:
- 3
- Protection class (When coupled):
- IP67
- Special Features:
- LED
- Approvals:
- UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
