Turck Rsm Rkm 26-19M Cordset 100032451
Turck
$127.30
Manufacturer's Part Number: 100032451
Actuator and Sensor Cable. Extension Cable. Ident. no.: 100032451. 7/8 Male, Straight, 2-pin. 7/8 Female, straight, 2-pin. Flexible Service Cable. Yellow PVC jacket, 2X16 AWG. Sunlight Resistant. -40 Cold Bend Rating. Oil Resistant. Flame Ratings: UL 1100, CSA FT2
- Application:
- Signal
- Design:
- Double-ended
- Connector A:
- Male, 7/8-16 UN, Straight
- Connector B:
- Female, 7/8-16 UN, Straight
- Voltage:
- 600 V
- Current:
- 10 A
- Cable diameter:
- ?ÿ 9.6 mm
- Length (L):
- 19.0 m
- Cable jacket:
- PVC, Yellow
- Number of Conductors:
- 2
- Protection class (When coupled):
- IP67, IP68, IP69, IP69K
- Approvals:
- UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
- Flyer:
- View
- Catalog:
- View
- Datasheet:
- View
