Turck

Turck Rssd Rj45S 423-70M U-88558

(No reviews yet) Write a Review
SKU:
RSSD RJ45S 423-70M
Condition:
New
Application:
Data
Design:
Double-ended
Connector A:
Male, M12 ?ù 1, Straight, D-code
Number of contacts:
4
Connector body:
Plastic, TPU, Blue gray
Coupling nut:
Brass, CuZn, Nickel-plated
Connector B:
Male, RJ45, Straight
Number of contacts:
8
Connector body:
Plastic, TPU, Black
Fieldbus Protocol:
PROFINET
Voltage:
42 V
Current:
1.5 A
Cable diameter:
?ÿ 7.87 mm
Length (L):
70.0 m
Cable jacket:
TPE, Green
Protection class (When coupled):
IP67
Approvals:
UL 1863, FM Div.2, CE, UKCA, RoHS
Flyer:
View
Catalog:
View
Datasheet:
View
$551.10

Description

PROFINET Cordset. Extension Cable. Ident. no.: U-88558. Cable length: 70 m. M12, Male, Straight, 4-pin. Shield to coupling nut. D-code (reverse key). RJ45, Male, Straight, 8-pin, Shielded. Unshielded Twisted Pair. Industrial Ethernet Cable. fieldbus type: Ethernet CAT5E, Green TPE jacket, shielded, 2UTPX22 AWG. Sunlight Resistant. Oil Resistant. Flame Ratings: UL 1685, UL1061. Flexlife® and C-track rated
