WAGO 2075-381/997-404 Pack of 2000
Wago
$590.00
Through-Board SMD PCB Terminal BlockPin spacing 3 mm 1-pole
- For vertical wiring
- Wiring performed on the back of the LED module simplifies lighting manufacturing
- Low installation height minimizes on-board LED shadowing
- Compact design provides uniform light distribution
- An economical alternative to wire soldering
- For manual and automated wiring systems
The WAGO component equivalent to 2075381997404 is a specific part or product within the WAGO catalog, which is known for its high-quality electrical interconnection and automation solutions. This component is likely used in various industrial and commercial applications, providing reliable performance and compatibility with other WAGO products. It is essential for ensuring efficient and safe electrical connections, contributing to the overall functionality and reliability of the systems in which it is used.
- actuation type:
- Push-in
- clamping spring material:
- Copper alloy
- color:
- Silver-colored
- conductor connection direction to pcb:
- 90
- connection technology:
- PUSH WIRE
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- CH
- depth:
- 17.5 mm / 0.689 inch
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 3.9 mm / 0.154 inch
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- nominal voltage ii 2:
- 500 V
- note:
- Terminal block without insulation housing!Protection against accidental contact must be provided at voltages higher than low voltages(e.g., SELV/PELV) for the relevant application.
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- SMD
- pole no:
- 1
- rated current:
- 0.375
- rated current ul 1977:
- 0.375
- rated surge voltage ii 2:
- 4 kV
- rated voltage ul 1977:
- 600 V
- ratings per:
- IEC/EN 60664-1
- reel diameter of tape and reel packaging:
- 330 mm
- solder pin arrangement:
- In-line
- solid conductor:
- 0.34 0.75 mm / 20 18 AWG
- strip length:
- 3.7 mm / 0.15 inch
- tape width:
- 24 mm
- weight:
- 0.160 g
- width:
- 3 mm / 0.118 inch
