WAGO 218-502/000-604 THR PCB terminal block; Locking slides; 0.5 mm²; Pin spacing 2.54 mm; 2-pole; CAGE CLAMP; 0,50 mm²; black
THR PCB terminal block; Locking slides; 0.5 mm²; Pin spacing 2.54 mm; 2-pole; CAGE CLAMP; 0,50 mm²; black.
The WAGO component equivalent to 218502000604 is a specific part used in electrical and electronic applications, known for its reliability and efficiency. This component is designed to meet high standards of performance and is commonly utilized in various industrial and commercial settings. It ensures secure and stable connections, making it a preferred choice for professionals in the field.
- actuation type:
- Slider
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Black
- conductor connection direction to pcb:
- 40
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 13 mm / 0.512 inch
- fine stranded conductor:
- 0.08 0.5 mm / 28 20 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 mm
- fire load:
- 0.011 MJ
- flammability class per ul94:
- V2
- height:
- 10.9 mm / 0.429 inch
- height from the surface:
- 8.1 mm / 0.319 inch
- insulation material:
- Polyamide (PA46)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- IIIa
- nominal voltage ii 2:
- 320 V
- nominal voltage iii 3:
- 32 V
- note conductor cross section:
- Terminating 0.75 mm/18 AWG conductors is possible: however insulation diameter allows only every other clamping unit to be terminated with this conductor size.
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THR
- pin spacing:
- 2.54 mm / 0.1 inch
- plated through hole diameter thr:
- 1.1 (+0.1) mm
- pole no:
- 2
- rated current:
- 0.25
- rated surge voltage ii 2:
- 2.5 kV
- rated surge voltage iii 2:
- 2.5 kV
- rated surge voltage iii 3:
- 2.5 kV
- rated voltage iii 2:
- 160 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.5 x 0.75 mm
- solder pin length:
- 2.8 mm
- solid conductor:
- 0.08 0.5 mm / 28 20 AWG
- strip length:
- 5 6 mm / 0.2 0.24 inch
- weight:
- 0.728 g
- width:
- 6.58 mm / 0.259 inch
