WAGO 2210-1307
Wago
$12.39
TOPJOBS ground terminal block with Push-buttons; rail mount; 3-conductor; 10 mm wide; green-yellow.
The WAGO 2210 TOPJOB S series ground/earthing terminal block is designed for Ex e II applications and features a 1-deck/level configuration with both side/lateral and center marking slots. It includes a test port and is green-yellow in color. The terminal block supports 1 grounding/protective-earth (1PE) connection and accommodates 3 wires (1 push-in + 2 push-in) with a nominal cross-section of 10mm², suitable for wire sizes ranging from 0.5mm² to 16mm² or #20AWG to #6AWG. It utilizes Push-in CAGE CLAMP spring connections and mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) with a 10mm width, equivalent to model 22101307.
- actuation type:
- Push-in || Push-button || Operating tool
- color:
- Green-yellow
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 36.9 mm / 1.453 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.5 16 mm / 20 6 AWG
- fine stranded conductor with ferrule push in termination:
- 4 10 mm / 12 8 AWG
- fine stranded conductor with insulated ferrule:
- 0.5 10 mm / 20 8 AWG
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 89 mm / 3.504 inch
- insulation material:
- Polyamide (PA66)
- marking level:
- Center/side marking
- mounting type:
- DIN-35 rail
- nominal cross section:
- 10 mm
- note conductor cross section:
- Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- packaging type:
- Box
- ratings per:
- IEC/EN 60947-7-2
- solid conductor:
- 0.5 16 mm / 20 6 AWG
- solid conductor push in termination:
- 2.5 16 mm / 14 6 AWG
- strip length:
- 17 19 mm / 0.67 0.75 inch
- weight:
- 37.525 g
- width:
- 10 mm / 0.394 inch
- wiring direction:
- Front-entry wiring
