CLASSIC Splicing Connectorfor all conductor types, gray, 150 piece jar
Electrical Data
- Rated voltage (II / 2): 400 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 32 A
- Legend (ratings): (II / 2) Overvoltage category II / Pollution degree 2
Connection Data
- Connection technology: CAGE CLAMP<sup></sup>
- Actuation type: Lever
- Connectable conductor materials: Copper
- Solid conductor: 0.08 2.5 mm / 28 12 AWG
- Stranded conductor: 0.08 2.5 mm / 28 12 AWG
- Fine-stranded conductor: 0.08 4 mm / 28 12 AWG
- Strip length: 9 10 mm / 0.35 0.39 inch
- Total number of connection points: 5
- Total number of potentials: 1
- Type of wiring: Side-entry wiring
Geometrical Data
- Width: 26.6 mm / 1.047 inch
- Height: 14.5 mm / 0.571 inch
- Depth: 20.5 mm / 0.807 inch
Material Data
- Color: gray
- Flammability class per UL94: V0
- Fire load: 0.130 MJ
- Weight: 6.581 g
Environmental Requirements
- Surrounding air (operating) temperature: 40 C
- Continuous operating temperature: 85 C
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918464956
- Customs Tariff No.: 85369010000
The WAGO component equivalent to 222415PW250150 is a specific type of electrical connector known for its reliability and ease of use in various electrical installations. This component is designed to provide secure and efficient connections for electrical wires, ensuring stable and safe electrical circuits. It is commonly used in both residential and commercial applications, offering a practical solution for connecting multiple wires without the need for traditional screw terminals. The WAGO connector is appreciated for its compact design, ease of installation, and ability to accommodate different wire sizes, making it a versatile choice for electricians and DIY enthusiasts alike.
