WAGO 2636-1352
Wago
$7.53
PCB terminal block; 16 mm; Pin spacing 15 mm; 2-pole; Push-in CAGE CLAMP; 16,00 mm; gray
- CB terminal strips with Push-in CAGE CLAMP connection
- Push-in termination of solid and ferruled conductors
- Ideal for panel feedthrough applications via operation parallel to conductor entry
- Testing can be performed both parallel and perpendicular to conductor entry
The WAGO component equivalent to 26361352 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and stable connections in various applications. This component is known for its high quality, durability, and ease of use, making it a preferred choice for professionals in the industry. It is compatible with a range of systems and can be integrated seamlessly to enhance performance and reliability in electrical installations.
- actuation type:
- Operating tool
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 0
- connection technology:
- Push-in CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- DE
- depth:
- 29.1 mm / 1.146 inch
- drilled hole diameter with tolerance:
- 1.7 (+0.1) mm
- fine stranded conductor:
- 0.75 25 mm / 18 4 AWG
- fine stranded conductor with insulated ferrule:
- 0.75 16 mm
- fine stranded conductor with twin ferrule:
- 0.75 6 mm
- fine stranded conductor with uninsulated ferrule:
- 0.75 16 mm
- fire load:
- 0.052 MJ
- flammability class per ul94:
- V0
- height:
- 32.6 mm / 1.283 inch
- height from the surface:
- 28.6 mm / 1.126 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mounting type:
- Feed-through mounting
- nominal voltage ii 2:
- 1000 V
- nominal voltage iii 3:
- 1000 V
- number of solder pins per potential:
- 6
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 15 mm / 0.591 inch
- pole no:
- 2
- rated current:
- 76 A
- rated current csa use group b:
- 66 A
- rated current csa use group c:
- 66 A
- rated current csa use group d:
- 66 A
- rated current ul use group b:
- 85 A
- rated current ul use group c:
- 85 A
- rated current ul use group d:
- 0.208333333333333
- rated surge voltage ii 2:
- 8 kV
- rated surge voltage iii 2:
- 8 kV
- rated surge voltage iii 3:
- 8 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group c:
- 300 V
- rated voltage csa use group d:
- 600 V
- rated voltage iii 2:
- 1000 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group c:
- 300 V
- rated voltage ul use group d:
- 600 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 1.2 x 1 mm
- solder pin length:
- 4 mm
- solid conductor:
- 0.75 16 mm / 18 4 AWG
- strip length:
- 18 20 mm / 0.71 0.79 inch
- weight:
- 20.198 g
- width:
- 26.6 mm / 1.047 inch
