Shield terminal block; 4-conductor; 28-16 AWG; 4 mm wide.
The WAGO 279 series shield terminal block is a white, 1-deck/level component with a center marking slot, designed for 1 shield-through pole and accommodating 4 wires using 2 clamps on each side. It supports wire sizes from 0.08mm² to 1.5mm² or #28AWG to #16AWG and features CAGE CLAMP spring connections. The terminal block mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 4mm, equivalent to model 279838.
- actuation type:
- Operating tool
- color:
- White
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 27 mm / 1.063 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 1.5 mm / 28 16 AWG
- fire load:
- 0.208 MJ
- flammability class per ul94:
- V0
- height:
- 73 mm / 2.874 inch
- insulation material:
- Polyamide (PA66)
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- packaging type:
- Box
- ratings per:
- IEC/EN 60947-7-2
- solid conductor:
- 0.08 1.5 mm / 28 16 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 13.382 g
- width:
- 4 mm / 0.157 inch
- wiring direction:
- Front-entry wiring
