POWER CAGE CLAMP feedthrough terminal block; DIN 35 x 15 rail mount; 2-conductor; 2 AWG; 16 mm wide; blue.
The WAGO 285 series neutral-through terminal block is a blue, single-deck component designed for neutral-through pole (N) connections, accommodating two wires with one clamp each. It supports a rated current of 125A and features CAGE CLAMP spring connections for secure wiring. The terminal block is mounted on a DIN-35 rail (35 x 15) and has a width of 16mm. It includes side/lateral marking slots and is equivalent to model 285604.
- actuation type:
- Operating tool
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 52.5 mm / 2.067 inch
- design:
- Horizontal type
- fire load:
- 1.162 MJ
- flammability class per ul94:
- V0
- height:
- 115.5 mm / 4.547 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 800 V
- packaging type:
- Box
- rated current:
- 125 A
- rated surge voltage iii 3:
- 8 kV
- ratings per:
- IEC/EN 60947-7-1
- solid conductor:
- 6 35 mm / 8 2 AWG
- strip length:
- 23 mm / 0.91 inch
- weight:
- 131.314 g
- width:
- 16 mm / 0.63 inch
- wiring direction:
- Front-entry wiring
