WAGO 713-1102/107-000 1-conductor female connector, 2-row; CAGE CLAMP; 1.5 mm²; Pin spacing 3.5 mm; 4-pole; 100% protected against mismating; Screw flange; 1,50 mm²; black
Wago
$6.33
(No reviews yet)
Write a Review
Write a Review
Wago
WAGO 713-1102/107-000 1-conductor female connector, 2-row; CAGE CLAMP; 1.5 mm²; Pin spacing 3.5 mm; 4-pole; 100% protected against mismating; Screw flange; 1,50 mm²; black
1-conductor female connector, 2-row CAGE CLAMP, black.
The WAGO component equivalent to 7131102107000 is a specific part used in electrical and electronic applications, known for its reliability and efficiency. This component is designed to provide secure and maintenance-free connections, ensuring optimal performance in various industrial and commercial settings. It is commonly utilized in automation, control systems, and other technical environments where dependable connectivity is crucial.
- actuation type:
- Operating tool
- anti rotation protection:
- Yes
- approvals per:
- UL 1059
- clamping spring material:
- Chrome-nickel spring steel (CrNi)
- color:
- Black
- conductor entry direction to mating direction:
- 0 °
- connection technology:
- CAGE CLAMP®
- CONNECTOR CONNECTION TYPE:
- For conductor
- CONTACT MATERIAL:
- Copper alloy
- CONTACT PLATING:
- Tin
- CONTACT TYPE PLUGGABLE CONNECTOR:
- Female connector/socket
- COUNTRY OF ORIGIN VKORG GERMANY:
- PL
- CUSTOMS TARIFF NUMBER VKORG GERMANY:
- 85366990990
- DEPTH:
- 16 mm / 0.63 inches
- FINE STRANDED CONDUCTOR:
- 0.08 ¢¦ 1.5 mm² / 28 ¢¦ 16 AWG
- FINE STRANDED CONDUCTOR WITH INSULATED FERRULE:
- 0.25 ¢¦ 1 mm²
- FINE STRANDED CONDUCTOR WITH UNINSULATED FERRULE:
- 0.25 ¢¦ 1 mm²
- FIRE LOAD:
- 0.048 MJ
- FLAMMABILITY CLASS PER UL94:
- V0
- HEIGHT:
- 18.8 mm / 0.74 inches
- INSULATION MATERIAL:
- Glass fiber-reinforced polyamide (PA66 GF)
- LEGEND RATINGS:
- (III / 2) ¢ Overvoltage category III / Pollution degree 2
- LIMIT TEMPERATURE RANGE:
- -60 ¢¦ +100 °C
- LOCKING OF PLUG IN CONNECTION:
- Screw flange
- MATERIAL GROUP:
- II
- MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE:
- MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2=
- MISMATING PROTECTION:
- YesMOUNTING NOTE=
- NOMINAL VOLTAGE II 2:
- 250 V
- NOMINAL VOLTAGE III 3:
- 80 V
- NOTE MATERIAL DATA:
- Information on material data can be found here
- PIN SPACING:
- 3.5 mm / 0.138 inches
- PLUGGING WITHOUT LOSS OF PIN SPACING:
- No
- POLE NUMBER:
- 4
- PROCESSING TEMPERATURE:
- -35 ¢¦ +60 °C
- PRODUCT GROUP CODE:
- 3
- RATED CURRENT:
- 0.416666666666667
- RATED CURRENT CSA USE GROUP B:
- 0.416666666666667
- RATED CURRENT UL USE GROUP B:
- 0.416666666666667
- RATED CURRENT UL USE GROUP C:
- 0.416666666666667
- RATED IMPULSE VOLTAGE III 2:
- 2.5 kV
- RATED IMPULSE VOLTAGE III 3:
- 2.5 kV
- RATED SURGE VOLTAGE II 2:
- 2.5 kV
- RATED VOLTAGE CSA USE GROUP B:
- 300 V
- RATED VOLTAGE III 2:
- 160 V
- RATED VOLTAGE UL USE GROUP B:
- 300 V
- RATED VOLTAGE UL USE GROUP C:
- 50 V
- RATINGS PER:
- IEC/EN 60664-1
- SAFETY INFORMATION 1:
- The MCS ¢ MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load.When used as intended, these conne
- SOLID CONDUCTOR:
- 0.08 ¢¦ 1.5 mm² / 28 ¢¦ 16 AWG
- STRIP LENGTH:
- 6 ¢¦ 7 mm / 0.24 ¢¦ 0.28 inches
- VARIABLE CODING:
- Yes
- VARIANTS:
- Other pole numbers || Gold-plated or partially gold-plated contact surfaces || Other versions (or variants) can be requested from WAGO Sales or configured at https://configurator.wago.com/.
- WEIGHT:
- 3.080 g
- WIDTH:
- 17.1 mm / 0.673 inches
