dielectric strength control load circuit ac 1 min:
2.5 kVrms
fine stranded conductor:
0.08 2.5 mm / 28 14 AWG
fire load:
0.313 MJ
height:
91 mm / 3.583 inch
input voltage range high level:
DC 2 6.25 V
input voltage range low level:
DC 0 0.8 V
insulation type adjacent devices:
Reinforced insulation (safe isolation)
insulation type control load circuit:
Basic insulation
leakage current at rated voltage:
¤ 25 A
limiting continuous current:
0.1 A
mounting type:
DIN-35 rail
nominal input current at un:
17 mA
nominal input voltage un:
DC 5 V
nominal output voltage:
DC 24 V
note:
Optocouplers and solid state relays are designed for use in signal processing networks, which are not supplied by the low-voltage power supply networks.
operating altitude max:
2000 m
output voltage range:
DC 3 30 V
overvoltage category:
II
packaging type:
Box
pollution degree:
2
processing temperature:
-25 +50 C
rated voltage:
300 V
relative humidity:
5 95 % (no condensation permissible)
solid conductor:
0.08 2.5 mm / 28 14 AWG
standards specifications:
EN 61010-2-201 || EN 61000-6-3 || EN 61000-6-4 || EN 50121-3-2 || EN 61373 || UL 508
