Stackable PCB terminal block; 4 mm²; Pin spacing 5 mm; 1-pole; CAGE CLAMP; 4,00 mm²; orange.
The WAGO component equivalent to 7453806 is a specific part or model within the WAGO product line, which is known for its high-quality electrical interconnection and automation solutions. This component is designed to meet the same specifications and performance standards as the 7453806, ensuring compatibility and reliability in various applications. WAGO components are widely used in industrial, commercial, and residential settings for their durability and efficiency in electrical connections and automation systems.
- actuation type:
- Operating tool
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Orange
- conductor connection direction to pcb:
- 45
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 19.4 mm / 0.764 inch
- drilled hole diameter with tolerance:
- 1.5 (+0.1) mm
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 2.5 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 2.5 mm
- fire load:
- 0.026 MJ
- flammability class per ul94:
- V0
- height:
- 23 mm / 0.906 inch
- height from the surface:
- 19 mm / 0.748 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 1
- rated current:
- 32 A
- rated current csa use group b:
- 20 A
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 20 A
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.8 x 1.2 mm
- solder pin length:
- 4 mm
- solid conductor:
- 0.08 4 mm / 28 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 1.725 g
- width:
- 6.5 mm / 0.256 inch
