Wago 750-331

WAGO 750-331

Wago
SKU:
750-331
Availability:
Contact us to confirm availability and lead times.
$938.80
Condition:
New
Current Stock:
Description
Fieldbus Coupler PROFIBUS DP; Fiber-optic connection; 1.5 MBd

Technical Data
  • Communication: PROFIBUS
  • Topology: Subring, single-fiber ring
  • Number of fieldbus nodes on the master max.: 10
  • Baud rate: 93.75 kBd ˜ 1.5 MBd
  • Fieldbus segment length max.: 25 m
  • Transmission medium: APF (plastic) fiber (1000m)
  • Number of modules per node max.: 64
  • Input and output process image (Fieldbus) max.: 128 Byte/128 Byte
  • System supply voltage: DC 24 V(-15 ˜ +20 %); via wiring level (CAGE CLAMP<sup></sup> connection)
  • Current consumption, system supply (5 V): 350 mA
  • Total current for system supply: 1650 mA
  • Field supply voltage: DC 24 V (-15 ˜ +20 %); via power jumper contacts
  • Input current typ. at rated load (24 V): 500 mA
  • Efficiency of the power supply (typ.) at nominal load (24 V): 87 %
  • Isolation: 500 V system/supply
  • Number of outgoing power jumper contacts: 3
  • Current carrying capacity of the power jumper contacts: 10 A
  • Standard: EN 50170
Connection Data
  • Connection technology: communication/fieldbus: PROFIBUS: 1 x HP Simplex, FOC plug included with delivery
  • Connection technology: field supply: 6 x CAGE CLAMP<sup></sup>
  • Connection technology: system supply: 2 x CAGE CLAMP<sup></sup>
  • Connection technology: Device configuration: 1 x 4-pole male connector
  • Connection type (1): System/field supply
  • Solid conductor: 0.08 ˜ 2.5 mm / 28 ˜ 14 AWG
  • Fine-stranded conductor: 0.08 ˜ 2.5 mm / 28 ˜ 14 AWG
  • Strip length: 8 ˜ 9 mm / 0.31 ˜ 0.35 inch
Geometrical Data
  • Width: 50.5 mm / 1.988 inch
  • Height: 71.1 mm / 2.799 inch
  • Height from upper-edge of DIN-35 rail: 63.9 mm / 2.516 inch
  • Depth: 100 mm / 3.937 inch
Mechanical Data
  • Type of mounting: DIN-35 rail
Material Data
  • Color: light gray
  • Housing material: Polycarbonate, polyamide 6.6
  • Fire load: 0.000 MJ
  • Weight: 191.000 g
  • Conformity marking: CE
Environmental Requirements
  • Surrounding air (operating) temperature: 0 ˜ 55 C
  • Surrounding air (storage) temperature: -40 ˜ 85 C
  • Protection class: IP20
  • Degree of pollution (5): 2 per IEC 61131-2
  • Operating altitude: 0 ˜ 2000 m
  • Mounting position: horizontal (standing/lying) or vertical
  • Relative air humidity (no condensation): 95 %
  • Vibration resistance: acc. to IEC 60068-2-6
  • Shock resistance: 15g per IEC 60068-2-27
  • EMC immunity to interference: acc. to EN 61000-6-2
  • EMC emission of interference: acc. to EN 61000-6-4
  • Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
  • Permissible H<sub>2</sub>S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
  • Permissible SO<sub>2</sub> contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm
Commercial data
  • Packaging type: BOX
  • Country of origin: DE
  • GTIN: 4050821286042
  • Customs Tariff No.: 85176200000
.

The WAGO 750 series Fieldbus coupler, also known as a remote I/O (RIO) controller unit, supports PROFIBUS DP communication with a data rate of 1.5MBd and can handle up to 64 connections per node and 10 fieldbus nodes on a master connection. It operates on a 24Vdc supply voltage via system wiring and power jumper, featuring a 4-pin male connector for fieldbus, spring CAGE CLAMP for power supply connections, and another 4-pin male connector for device configuration. Designed for DIN-35 rail mounting with a width of 50.5mm, it is rated for an ambient temperature range of 0°C to +55°C and has an IP20 protection rating, equivalent to model 750331.

Additional Information
baud rate:
93.75 kBd 1.5 MBd
bus segment length max:
25 m
color:
Light gray
communication:
PROFIBUS
conformity marking:
CE
connection technology communication fieldbus:
PROFIBUS: 1 x HP Simplex, FOC plug included with delivery
connection technology device configuration:
1 x Male connector: 4-pole
connection technology field supply:
6 x CAGE CLAMP
connection technology system supply:
2 x CAGE CLAMP
connection type 1:
System/field supply
country of origin sales organisation germany:
DE
current carrying capacity power jumper contacts:
0.416666666666667
depth:
71.1 mm / 2.799 inch
depth from upper edge of din rail:
63.9 mm / 2.516 inch
emc emission of interference:
Per EN 61000-6-4
emc immunity to interference:
Per EN 61000-6-2
exposure to pollutants:
Per IEC 60068-2-42 and IEC 60068-2-43
fine stranded conductor:
0.08 2.5 mm / 28 14 AWG
fire load:
0.000 MJ
height:
100 mm / 3.937 inch
housing material:
Polycarbonate: polyamide 6.6
input and output fieldbus process image max:
128 Byte/128 Byte
input current typ at nominal load 24 v:
500 mA
isolation:
500 V system/field
mounting position:
Horizontal (standing/lying): vertical
mounting type:
DIN-35 rail
note:
Note: Configuration files required (GSD)!
number of fieldbus nodes on master max:
10
number of modules per node max:
64
number of outgoing power jumper contacts:
3
operating altitude:
0 2000 m
packaging type:
Box
permissible h2s contaminant concentration at a relative humidity 75:
10 ppm
permissible so2 contaminant concentration at a relative humidity 75:
25 ppm
pollution degree 5:
2 per IEC 61131-2
power consumption 5 v system supply:
350 mA
power supply efficiency typ at nominal load 24 v:
0.87
protection type:
IP20
relative humidity without condensation:
0.95
shock resistance:
15g per IEC 60068-2-27
solid conductor:
0.08 2.5 mm / 28 14 AWG
standard:
EN 50170
strip length:
8 9 mm / 0.31 0.35 inch
supply voltage field:
24 VDC (-15 +20 %): via power jumper contacts
supply voltage system:
24 VDC (-15 +20 %): via pluggable connector (CAGE CLAMP connection)
surrounding air temperature operation:
0 55 C
surrounding air temperature storage:
-40 85 C
topology:
Subring (single-fiber)
total current system supply:
1650 mA
transmission medium:
APF (All Plastic Fiber) (1000 m)
vibration resistance:
Per IEC 60068-2-6
weight:
191.000 g
width:
50.5 mm / 1.988 inch
