Fieldbus Coupler PROFIBUS DP; 12 MBd; ECO
View AllClose
Technical Data
- Communication: PROFIBUS
- Number of fieldbus nodes on the master max.: 125
- Max. no. of I/O points: 6000
- Baud rate: 9.6 kBd 12 MBd
- Fieldbus segment length max.: 1200 m
- Transmission medium: Cu cable acc. to EN 50170
- Transmission time: typ. 1 ms (10 couplers; 32 digital I/Os per coupler at 12 Mbaud) max. 3.3 ms
- Number of modules per node max.: 63
- Input and output process image (Fieldbus) max.: 32 Byte/32 Byte
- System supply voltage: DC 24 V(-25 +30 %); via wiring level
- Current consumption, system supply (5 V): 350 mA
- Total current for system supply: 650 mA
- Input current typ. at rated load (24 V): 260 mA
- Efficiency of the power supply (typ.) at nominal load (24 V): 80 %
- Standard: EN 50170
Connection Data
- Connection technology: communication/fieldbus: PROFIBUS: 1 x D-Sub 9 socket
- Connection technology: system supply: 4 x CAGE CLAMP<sup></sup>
- Connection technology: Device configuration: 1 x 4-pole male connector
- Connection type (1): System supply
- Solid conductor: 0.08 1.5 mm / 28 16 AWG
- Fine-stranded conductor: 0.08 1.5 mm / 28 16 AWG
- Strip length: 5 6 mm / 0.2 0.24 inch
- Note (conductor cross-section): 14 AWG: THHN, THWN
Geometrical Data
- Width: 49.5 mm / 1.949 inch
- Height: 71.9 mm / 2.831 inch
- Height from upper-edge of DIN-35 rail: 64.7 mm / 2.547 inch
- Depth: 96.8 mm / 3.811 inch
Mechanical Data
- Type of mounting: DIN-35 rail
Material Data
- Color: light gray
- Housing material: Polycarbonate, polyamide 6.6
- Fire load: 0.000 MJ
- Weight: 110.425 g
- Conformity marking: CE
Environmental Requirements
- Surrounding air (operating) temperature: 0 55 C
- Surrounding air (storage) temperature: -40 85 C
- Protection class: IP20
- Degree of pollution (5): 2 per IEC 61131-2
- Operating altitude: 0 2000 m
- Mounting position: horizontal (standing/lying) or vertical
- Relative air humidity (no condensation): 95 %
- Vibration resistance: 4g per IEC 60068-2-6
- Shock resistance: 15g per IEC 60068-2-27
- EMC immunity to interference: acc. to EN 61000-6-2, marine applications
- EMC emission of interference: acc. to EN 61000-6-4, marine applications
- Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
- Permissible H<sub>2</sub>S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
- Permissible SO<sub>2</sub> contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4045454422554
- Customs Tariff No.: 85176200000
The WAGO 750 series Eco version Fieldbus coupler/head (remote I/O controller unit) with PROFIBUS DP communication capability supports 12MBd data rates and can connect up to 63 connections per node and 125 fieldbus nodes on the master connection. It operates on a 24Vdc supply voltage via system wiring and features a 9-pin D-sub female connector for fieldbus, a spring CAGE CLAMP for power supply connections, and a 4-pin male connector for device configuration. Designed for DIN-35 rail mounting with a width of 49.5mm, it is rated for IP20 protection and suitable for ambient temperatures ranging from 0°C to +55°C, equivalent to model 750343.
