WAGO 750-346

(No reviews yet) Write a Review

Write a Review

WAGO 750-346

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

750-346

UPC:

MPN:

750-346

Condition:

New

baud rate:

500 kBd (125 kBd, 250 kBd, 500 kBd)

bus segment length max:

500 m

color:

Light gray

communication:

DeviceNet

conformity marking:

CE

connection technology communication fieldbus:

DeviceNet: 1 x Male connector: 5-pole

connection technology device configuration:

1 x Male connector: 4-pole

connection technology system supply:

4 x CAGE CLAMP

connection type 1:

System supply

country of origin sales organisation germany:

DE

depth:

71.9 mm / 2.831 inch

depth from upper edge of din rail:

64.7 mm / 2.547 inch

emc emission of interference:

Per EN 61000-6-4

emc immunity to interference:

Per EN 61000-6-2

exposure to pollutants:

Per IEC 60068-2-42 and IEC 60068-2-43

fine stranded conductor:

0.08 1.5 mm / 28 16 AWG

fire load:

1.613 MJ

height:

96.8 mm / 3.811 inch

housing material:

Polycarbonate: polyamide 6.6

input and output fieldbus process image max:

32 Byte/32 Byte

input current typ at nominal load 24 v:

260 mA

input current via devicenet interface at 11 v:

120 mA

mounting position:

Horizontal (standing/lying): vertical

mounting type:

DIN-35 rail

note:

Note: Configuration files required (EDS)!

note conductor cross section:

14 AWG: THHN, THWN

number of fieldbus nodes on master max:

64

number of i o points:

6000

number of modules per node max:

64

operating altitude:

0 2000 m

packaging type:

Box

permissible h2s contaminant concentration at a relative humidity 75:

10 ppm

permissible so2 contaminant concentration at a relative humidity 75:

25 ppm

pollution degree 5:

2 per IEC 61131-2

power consumption 5 v system supply:

350 mA

power supply efficiency typ at nominal load 24 v:

0.8

protection type:

IP20

relative humidity without condensation:

0.95

shock resistance:

15g per IEC 60068-2-27

solid conductor:

0.08 1.5 mm / 28 16 AWG

strip length:

5 6 mm / 0.2 0.24 inch

supply voltage system:

24 VDC (-15 +20 %): via pluggable connector

surrounding air temperature operation:

0 55 C

surrounding air temperature storage:

-40 85 C

total current system supply:

650 mA

transmission medium:

Shielded Cu cable: Remote bus cable: 2 x 0.82 mm + 2 x 1.7 mm: Drop cable: 2 x 0.2 mm + 2 x 0.32 mm

vibration resistance:

Per IEC 60068-2-6

weight:

115.000 g

width:

49.5 mm / 1.949 inch
