WAGO 756-1401/060-050
Wago
$78.02
CANopen-/DeviceNet cable, straight; 5 m; fitted on one end; A-coded; M12 socket, straight; one free cable end.
The WAGO component equivalent to 7561401060050 is a specific part used in various electrical and automation applications. It is designed to provide reliable and efficient connectivity solutions, ensuring seamless integration within systems. This component is known for its high quality, durability, and compatibility with other WAGO products, making it a preferred choice for professionals in the industry.
- bending cycles:
- 5 Mio.
- bending radius:
- 5 x cable diameter (min.)
- cable connection direction to mating direction:
- 0
- cable length:
- 5 m
- color:
- Violet
- communication fieldbus:
- CANopen
- communication fieldbus:
- DeviceNet
- conductor design:
- Bare copper wire (19 x 0.125 mm)
- conductor insulation:
- PE (halogen-free)
- conductor resistance:
- 57 /km (22 AWG) + 79 /km (24 AWG)
- connection type:
- M12 socket - Free end
- connector interface coding cable adapter 1 1:
- A-coded
- contact resistance:
- 10 m
- country of origin sales organisation germany:
- DE
- drag chain suitability:
- Yes
- fire load:
- 0.000 MJ
- housing material:
- TPU/TPU, black (~ RAL 9005)
- insulation resistance:
- 2 x 108 /km
- operating current:
- 0.166666666666667
- operating voltage:
- ¤ 300 V
- packaging type:
- Box
- pole no:
- 5
- pollution degree 5:
- 3/2 per IEC 60664-1
- protection type:
- IP67
- rated surge voltage:
- 2 kV
- sheathed cable diameter:
- 6.6 7.2 mm
- shield:
- Tinned copper braid, optical coverage approx. 85 %
- surrounding air operating temperature dynamic:
- -40 +80 C
- surrounding air operating temperature static:
- -40 +80 C
- tightening torque:
- 1 Nm
- type code:
- L-02YC11Y 2xAWG24 + 2xAWG22/1.4-120 VI FRNC, geschirmt
- weight:
- 345.700 g
