1-conductor female plug; straight; for insertion into carrier terminal blocks or male connectors; codable; can be commoned with miniature adjacent jumpers; 11-pole.
The WAGO component equivalent to 769111000006 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and stable connections in various applications. This component is known for its high quality, durability, and ease of installation, making it a preferred choice for professionals in the industry. It meets stringent standards and specifications, ensuring optimal performance and safety in electrical systems.
- actuation type:
- Operating tool
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- connector connection type:
- For conductor
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- DE
- depth:
- 18.3 mm / 0.72 inch
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fire load:
- 0.622 MJ
- flammability class per ul94:
- V0
- height:
- 45.2 mm / 1.78 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- module width:
- 5 mm / 0.197 inch
- nominal cross section:
- 4 mm
- nominal voltage iii 3:
- 500 V
- packaging type:
- Box
- pole no:
- 11
- rated current:
- 32 A
- rated surge voltage iii 3:
- 6 kV
- ratings per:
- IEC/EN 61984
- safety information 1:
- According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load.
- solid conductor:
- 0.08 4 mm / 28 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 35.951 g
- width:
- 55 mm / 2.165 inch
- wiring direction:
- Front-entry wiring
