| Description | Primary switch mode power supplies; EPSITRON ; ECO Power; 1-phase; 24 VDC; 2.5 A | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Remarks | Item description:
Output current Io: 2.5 A at 24 VDC and 110 240 VAC 2 A at 24 VDC and 100 240 VAC External fuse: Circuit breakers B6, B10; An external DC fuse is required for the DC input voltage Overload behavior: Constant power (in overload range: 1.05 ... 1.4 x Io); shutdown and automatic restart in the event of a short circuit | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Item properties | Miscellaneous
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Allow approximately 5 business days to ship. Need it sooner Contact us for assistance.
.The Eco switch-mode AC/DC power supply unit (SMPS PSU) from WAGO's Eco series provides a 24Vdc (SELV) output at 2.5A and 60W. It supports an input voltage range of 90-264Vac or 125-375Vdc, accommodating various single-phase AC or DC inputs. The unit features CAGE CLAMP spring connections and can be mounted on a DIN-35 rail or wall using screws, with a compact width of 40mm. It is rated for an ambient temperature range of -20°C to +60°C and has an IP20 protection rating, equivalent to model 7871712.
- actuation type:
- Operating tool
- color:
- Blue
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- connection technology 2:
- Screw-type connection
- country of origin sales organisation germany:
- IN
- depth from upper edge of din rail:
- 39.5 mm / 1.555 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.2 10 mm / 24 8 AWG
- fine stranded conductor 2:
- 6 35 mm / 10 2 AWG
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 89 mm / 3.504 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 800 V
- number of connection points:
- 3
- number of connection points 2:
- 1
- packaging type:
- Box
- rated current:
- 125 A
- rated surge voltage iii 3:
- 8 kV
- solid conductor:
- 0.2 10 mm / 24 8 AWG
- solid conductor 2:
- 6 35 mm / 10 2 AWG
- strip length:
- 12 14 mm / 0.47 0.55 inch
- torque:
- 3.5 Nm
- weight:
- 55.600 g
- width:
- 17.5 mm / 0.689 inch
- wiring direction:
- Front-/side-entry wiring
