DC/DC converter; input voltage 24 VDC; output voltage 5 VDC; 0.5 A.
The WAGO 787 series DC/DC power supply unit (PSU) / converter module provides a 5V DC output at 0.5A and 2.5W, with an input voltage range of 10-30V DC (24V DC nominal). It features a DC-OK relay contact output, Push-in CAGE CLAMP spring connections, and is designed for DIN-35 rail mounting with a 6mm width. The unit is rated for an ambient temperature range of -25°C to +70°C and has an IP20 protection rating, equivalent to model 7872801.
- color:
- Light gray
- country of origin sales organisation germany:
- DE
- depth:
- 19 mm / 0.748 inch
- fire load:
- 0.017 MJ
- height:
- 4.1 mm / 0.161 inch
- jumper assignment:
- 5-way
- nominal voltage iii 3:
- 800 V
- packaging type:
- Bag
- rated current:
- 25 A
- rated current ex e ii:
- 20 A
- weight:
- 2.431 g
- width:
- 24.3 mm / 0.957 inch
