WAGO 806-107 2-conductor PCB terminal block; 1.5 mm²; Pin spacing 5 mm; 7-pole; Push-in CAGE CLAMP; 1,50 mm²; gray
Wago
$5.96
(No reviews yet)
Write a Review
Write a Review
Wago
WAGO 806-107 2-conductor PCB terminal block; 1.5 mm²; Pin spacing 5 mm; 7-pole; Push-in CAGE CLAMP; 1,50 mm²; gray
2-conductor female connector; 1.5 mm²; Pin spacing 5 mm; 7-pole; 1,50 mm²; gray.
The WAGO component equivalent to 806107 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and maintenance-free connections. This component is typically used in various applications, including industrial automation, building technology, and process control, offering high performance and durability. The equivalent part ensures compatibility and seamless integration with existing systems, maintaining the standards and quality associated with WAGO products.
- actuation type:
- Operating tool
- approvals per:
- UL 1059
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 45
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For PCB
- contact material:
- Copper alloy
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- PL
- depth:
- 19.8 mm / 0.78 inch
- fine stranded conductor:
- 0.2 1.5 mm / 24 16 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 1 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 1 mm
- fire load:
- 0.176 MJ
- flammability class per ul94:
- V0
- height:
- 16.25 mm / 0.64 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mating direction to the pcb:
- 90
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 250 V
- packaging type:
- Box
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 7
- rated current:
- 0.416666666666667
- rated current csa use group b:
- 0.416666666666667
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin diameter:
- 1 mm
- solid conductor:
- 0.2 1.5 mm / 24 16 AWG
- strip length:
- 9 10 mm / 0.35 0.39 inch
- weight:
- 8.883 g
- width:
- 36.5 mm / 1.437 inch
