WAGO 811-414 2-conductor fuse terminal block light gray

Fuse terminal block; for class CC fuses; with blown fuse indication; 24 VDC; 1-pole

Electrical Data

• Rated current: 32 A

Connection Data

• Connection technology: CAGE CLAMP
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 2.5 16 mm / 14 6 AWG
• Fine-stranded conductor: 2.5 16 mm / 16 6 AWG
• Strip length: 12 13 mm / 0.47 0.51 inch
• No. of poles: 1
• Total number of connection points: 2
• Total number of potentials: 1
• Number of levels: 1
• Type of wiring: Side-entry wiring

Geometrical Data

• Width: 17.5 mm / 0.689 inch
• Height from upper-edge of DIN-35 rail: 55 mm / 2.165 inch
• Depth: 105 mm / 4.134 inch

Mechanical Data

• Design: horizontal
• Type of mounting: DIN-35 rail

Material Data

• Color: light gray
• Insulating material: Polyamide 66 (PA 66)
• Fire load: 0.000 MJ
• Weight: 1.111 g

Commercial data

• Packaging type: BOX
• GTIN: 4050821508304

.

The WAGO 811 series feed-through terminal block is a light gray, single-deck unit featuring a fused-disconnect for 10x38mm Class CC fuses and a blown-fuse indication at 24Vdc. It accommodates one feed-through pole with two wires using CAGE CLAMP spring connections, suitable for wire sizes ranging from 2.5mm² to 16mm² or #16AWG to #6AWG. Rated for a current of 32A, it mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 17.5mm. This terminal block is equivalent to model 811414.
