Busbar terminal block; for (10 x 3) mm busbars; 12-pole; without push-buttons; Push-in CAGE CLAMP; 4,00 mm²; light gray.
The WAGO 812 series terminal strip is a light gray, 1-deck/level, 1-pole (1P) connector that accommodates up to 12 wires using push-in connections. It supports wire sizes from 0.5mm² to 4mm² or #20AWG to #12AWG and is rated for a current of 96A. The terminal strip features Push-in CAGE CLAMP spring connections and mounts on a 10x3mm copper bar, equivalent to model 812101.
- actuation type:
- Operating tool
- color:
- Light gray
- connectable conductor materials:
- Copper
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- PL
- depth:
- 27.5 mm / 1.083 inch
- fine stranded conductor:
- 0.5 4 mm / 20 12 AWG
- fire load:
- 0.821 MJ
- height:
- 30 mm / 1.181 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- nominal voltage iii 3:
- 1000 V
- note on rated current 1:
- Current carrying capacity: With a maximum total current of 96 A, the clamping units of the busbar terminal block can be loaded with the rated current of the conductor cross-sections approved. This only applies when (10 x 3) mm busbars are used.
- packaging type:
- Box
- pole no:
- 12
- rated current:
- 96 A
- rated surge voltage iii 3:
- 6 kV
- solid conductor:
- 0.5 4 mm / 20 12 AWG
- solid conductor push in termination:
- 0.5 4 mm / 20 12 AWG
- stranded conductor:
- 0.5 4 mm / 20 12 AWG
- strip length:
- 11 mm / 0.43 inch
- weight:
- 35.628 g
- width:
- 75 mm / 2.953 inch
- wiring direction:
- Front-entry wiring
