WAGO 816-108 2-conductor PCB terminal block; 1.5 mm²; Pin spacing 5 mm; 8-pole; Push-in CAGE CLAMP; 1,50 mm²; gray
Wago
$11.23
(No reviews yet)
Write a Review
Write a Review
Wago
WAGO 816-108 2-conductor PCB terminal block; 1.5 mm²; Pin spacing 5 mm; 8-pole; Push-in CAGE CLAMP; 1,50 mm²; gray
2-conductor PCB terminal block; 1.5 mm; Pin spacing 5 mm; 8-pole; Push-in CAGE CLAMPp>
- Two-conductor terminal strips with screwdriver actuation and Push-in CAGE CLAMP<sup></sup> connection
- Double entries for supply and power distribution
- Simple, reliable connection via clamping units featuring individual operating slots
- Simple, push-in termination of solid and ferruled conductors
The WAGO component equivalent to 816108 is a specific part used in electrical and automation systems, known for its reliability and efficiency. This component is designed to facilitate secure and easy connections in various applications, ensuring optimal performance and safety. It is commonly used in industrial settings where robust and dependable electrical connections are crucial.
- actuation type:
- Operating tool
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 45
- connection technology:
- Push-in CAGE CLAMP
- contact material:
- Copper alloy
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- CH
- depth:
- 17 mm / 0.669 inch
- drilled hole diameter with tolerance:
- 1.1 (+0.1) mm
- fine stranded conductor:
- 0.2 1.5 mm / 24 16 AWG
- fine stranded conductor with insulated ferrule:
- 0.2 1 mm
- fine stranded conductor with uninsulated ferrule:
- 0.2 1.5 mm
- fire load:
- 0.184 MJ
- flammability class per ul94:
- V0
- height:
- 20.1 mm / 0.791 inch
- height from the surface:
- 16.6 mm / 0.654 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- number of solder pins per potential:
- 1
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 8
- rated current:
- 14 A
- rated current csa use group b:
- 0.333333333333333
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 0.8 x 0.5 mm
- solder pin length:
- 3.5 mm
- solid conductor:
- 0.2 1.5 mm / 24 16 AWG
- strip length:
- 9 10 mm / 0.35 0.39 inch
- weight:
- 9.570 g
- width:
- 41.5 mm / 1.634 inch
