THT male header; 1.2 x 1.2 mm solder pin; straight (90° to PCB); Pin spacing 10.16 mm; 5-pole.
The WAGO component equivalent to 8323605 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and stable connections in various applications. This component is known for its high quality, durability, and ease of installation, making it a preferred choice for professionals in the industry. It is compatible with a range of systems and can be used in different settings to enhance performance and reliability.
- actuation type:
- Operating tool
- color:
- Light gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CH
- depth from upper edge of din rail:
- 24.5 mm / 0.965 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 2.5 mm / 28 12 AWG
- fire load:
- 0.073 MJ
- flammability class per ul94:
- V0
- height:
- 32 mm / 1.26 inch
- marking level:
- Center marking
- mounting type:
- DIN-15 rail
- note conductor cross section:
- 12 AWG: THHN, THWN
- packaging type:
- Box
- rated current ex e ii:
- 23 A
- rated voltage en ex e ii:
- 690 V
- solid conductor:
- 0.5 2.5 mm / 20 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 3.798 g
- width:
- 6 mm / 0.236 inch
- wiring direction:
- Front-entry wiring
