Industrial-ECO-Switch; 5-port 100Base-TX; black.
The WAGO 852 series is a 5-port Industrial Eco Ethernet network switch with Ethernet/IP communication capability, designed for a supply voltage range of 12-48Vdc. It features 5 RJ45 ports (100BASE-TX) and can be mounted on a DIN-35 rail or wall, with a compact width of 23.4mm. The switch is rated IP30 and can operate in ambient temperatures ranging from -40°C to +70°C. It replaces the obsolete component 852-111 and is equivalent to part number 852111000001.
- Switching mode:
- Storeandforward; non-blocking
- Number of 100Base-TX ports:
- 5
- Communication standards:
- IEEE 802.3 10BASE-T; IEEE 802.3u 100BASE-TX; IEEE 802.3x Flow Control; IEEE 802.1p Prioritization
- MAC table (size):
- 2000 addresses
- Supply voltage:
- 12 ¦ 48 VDC
- Power consumption without PoE:
- 2W
- Baud rate:
- Copper cable: 10/100 Mbit/s
- Topology:
- Star
- Indicators:
- Device: LED (PWR) green: Power supply; per port: LED (100, LNK/ACT) green: Status 100 Mbps, LNK/ACT port 1 ¦ 5
- Connection technology: communication/fieldbus:
- Copper cable: 5 x RJ-45
- Connection technology: supply:
- 1 x Built-in male connector: 231-433/001-000; included female connector (MCS Connectors): 231-103/026-000
- Width:
- 23.4 mm / 0.921 inches
- Height:
- 109.2 mm / 4.299 inches
- Depth:
- 73.8 mm / 2.906 inches
- Depth from upper-edge of DIN-rail:
- 81 mm / 3.189 inches
- Weight:
- 203g
- Color:
- black
- Housing material:
- Sheet steel
- Ambient temperature (operation):
- -40 ¦ +70 °C
- Surrounding air temperature (storage):
- -40 ¦ +85 °C
- Protection type:
- IP30
- Relative humidity (without condensation):
- 95%
- Mounting type:
- DIN-35 rail
- Vibration resistance:
- per IEC 60068-2-6
- Shock resistance:
- per IEC 60068-2-27
