WAGO 857-640

(No reviews yet) Write a Review

Write a Review

WAGO 857-640

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

857-640

UPC:

MPN:

857-640

Condition:

New

bounce time typ:

3.5 ms

connection technology:

Push-in CAGE CLAMP

contact material relay:

AgSnO2

country of origin sales organisation germany:

DE

depth from upper edge of din rail:

97.8 mm / 3.85 inch

dielectric strength control load circuit ac 1 min:

4 kVrms

dielectric strength open contact ac 1 min:

1 kVrms

digital output do:

UN - 1 V : 100 mA

drop out time typ:

25 ms

electrical life no resistive load 23 c:

50 x 103 switching operations

fine stranded conductor:

0.34 2.5 mm / 22 14 AWG

fire load:

0.000 MJ

On-delay || On-delay (with control input) || Off-delay (with control input) || On- and off-delay (with control input) || Single-shot leading edge || Single-shot leading edge (with control input) || Single-shot trailing edge (with control input) || Si:

94 mm / 3.701 inch

input voltage range:

30 %

inrush current resistive max:

(AC) 20 A / 0.02 s

limiting continuous current:

0.25

mechanical life:

5 x 106 switching operations

minimum pulse length control input:

10 ms

mounting type:

DIN-35 rail

nominal input current at un:

18 mA

nominal input voltage un:

DC 24 V

number of changeover switchover contacts:

1

operating altitude max:

2000 m

packaging type:

Bag

pollution degree:

2

processing temperature:

-25 +50 C

protection type:

IP20

pull in time typ:

15 ms

rated surge voltage:

4 kV

rated voltage:

250 V

recommended minimum load:

10 V / 10 mA: 24 V / 1 mA

relative humidity:

5 95 % (no condensation permissible)

reset time:

50 ms

solid conductor:

0.34 2.5 mm / 22 14 AWG

standards specifications:

EN 61812-1 || EN 61373 || EN 50121-3-2 || UL 508

status indicator:

Yellow LED

strip length:

9 10 mm / 0.35 0.39 inch

surrounding air temperature operation at un:

-25 70 C

surrounding air temperature storage:

-40 70 C

switching capacity:

AC-15: 3 A / AC 250 V: DC-13: 2 A / DC 24 V

switching power resistive max:

AC 1500 VA: DC (see load limit curve)

switching voltage max:

AC 250 V

time range:

Adjustable: 0.01 0.1 s: 0.1 1 s: 1 10 s: 10 100 s: 1 10 min: 10 100 min: 1 10 h: 10 100 h

weight:

33.221 g

width:

6 mm / 0.236 inch
