WAGO 870-903 2-conductor through terminal block; 2.5 mm²; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 2,50 mm²; red
Wago
$1.80
2-conductor through terminal block; 2.5 mm²; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 2,50 mm²; red.
The WAGO 870 X-COM series feed-through terminal block is a red, single-deck unit with side and center marking slots, designed for one feed-through pole and two wires (one clamp each). It accommodates wire sizes from 0.08mm² to 4mm² (#28AWG to #12AWG) and supports a rated current of 24A. Featuring CAGE CLAMP spring connections, it mounts on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 5mm, equivalent to model 870903.
- actuation type:
- Operating tool
- color:
- Red
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 27.5 mm / 1.083 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fine stranded conductor with insulated ferrule:
- 0.08 1.5 mm / 28 14 AWG
- fire load:
- 0.080 MJ
- flammability class per ul94:
- V0
- height:
- 44.5 mm / 1.752 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 500 V
- packaging type:
- Box
- rated current:
- 24 A
- rated surge voltage iii 3:
- 6 kV
- ratings per:
- IEC/EN 60947-7-1
- safety information 1:
- Max. insulation diameter: 4.4 mm
- solid conductor:
- 0.08 2.5 mm / 28 12 AWG
- strip length:
- 6 7 mm / 0.24 0.28 inch
- weight:
- 4.313 g
- width:
- 5 mm / 0.197 inch
- wiring direction:
- Front-entry wiring
