WAGO 870-967/999-950

Wago
SKU:
51176794
$10.41
Condition:
New
Current Stock:
Double-deck terminal block; Ground conductor/through terminal block; 2.5 mm²; PE/L; suitable for Ex e II applications; for DIN-rail 35 x 15 and 35 x 7.5; CAGE CLAMP; 2,50 mm²; light gray.

The WAGO 870 X-COM series terminal block is a light gray, double-deck feed-through and ground/earthing terminal block with side marking slots, suitable for Ex e II applications. It features a "PE/L" marking and includes one feed-through pole and a protective-earth (1P+PE) configuration, accommodating four wires with two clamps each (2+2). It supports wire sizes from 0.08mm² to 4mm² (#28AWG to #12AWG) and is rated for a current of 18A. The terminal block uses CAGE CLAMP spring connections and is designed for mounting on a DIN-35 rail (35 x 15 / 35 x 7.5) with a width of 5mm, equivalent to model 870967999950.

actuation type:
Operating tool
color:
Light gray
connectable conductor materials:
Copper
connection technology:
CAGE CLAMP
country of origin sales organisation germany:
DE
depth from upper edge of din rail:
40 mm / 1.575 inch
design:
Horizontal type
fine stranded conductor:
0.08 4 mm / 28 12 AWG
fine stranded conductor with insulated ferrule:
0.08 1.5 mm / 28 14 AWG
fire load:
0.000 MJ
flammability class per ul94:
V0
height:
70 mm / 2.756 inch
marking level:
Side marking
mounting type:
DIN-35 rail
packaging type:
Box
rated current:
18 A
rated voltage en ex e ii:
440 V
ratings per:
IEC/EN 60947-7-1
safety information 1:
Max. insulation diameter: 4.4 mm
solid conductor:
0.08 2.5 mm / 28 12 AWG
strip length:
6 7 mm / 0.24 0.28 inch
weight:
13.891 g
width:
5 mm / 0.197 inch
wiring direction:
Front-entry wiring
