Description
Luminaire disconnect connector yellow, 500 pc bag
View AllClose
Electrical Data
- Rated voltage (II / 2): 400 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 6 A
- Ratings according to 2: EN 61984
Connection Data
- Connection type (1): Plug
- Connection technology: PUSH WIRE<sup></sup>
- Actuation type: Push-in
- Connectable conductor materials: Copper
- Solid conductor: 0.75 4 mm / 18 12 AWG
- Stranded conductor: 1.5 2.5 mm / 16 12 AWG
- Strip length: 11 13 mm / 0.43 0.51 inch
- No. of poles: 3
- Connection type (2): Socket
- Solid conductor (2): 0.75 mm / 18 AWG
- Strip length (2): 9 11 mm / 0.35 0.43 inch
- Total number of connection points: 9
- Total number of potentials: 3
Geometrical Data
- Width: 19 mm / 0.748 inch
- Height: 13.2 mm / 0.52 inch
- Depth: 42 mm / 1.654 inch
Material Data
- Color: yellow
- Fire load: 0.144 MJ
- Weight: 6.920 g
Commercial data
- Packaging type: BOX
- Country of origin: CN
- GTIN: 4045454671815
- Customs Tariff No.: 85366990990
