Baumer FLDM 170C1011/S42 10153178
Baumer
The Baumer FLDM 170C1011/S42 10153178 is a high-performance sensor designed for precise measurement and detection tasks. It features a measuring distance of 0 to 90 mm with an optimum operating distance of 70 mm, and can handle counting rates up to 3,000,000 copies per hour. The sensor is capable of detecting object speeds up to 5 m/sec and can manage object cycle distances greater than 1 mm. It is equipped with a pulsed red laser diode light source, emitting at a wavelength of 670 nm, and includes a visible red laser line measuring point for accuracy. The device offers enhanced functionality with features like synchronization input, direct gap detection, and sensitivity adjustments, including four preset levels or custom settings. It supports a voltage supply range of 10 to 30 VDC and includes safety features such as short circuit and reverse polarity protection. The sensor's robust die-cast zinc housing and glass front optics are designed to operate within a temperature range of 0 to +50 °C and are rated IP 54 for protection against dust and splashing water. Connectivity is facilitated through a serial interface compatible with ScaDiag software, and it includes both DIN 45322 6-pin and DIN 45326 8-pin connectors for versatile integration.
