The Baumer UNDK 10U6914/KS35A 10161450 is an ultrasonic sensor designed for precise distance measurement within a scanning range of 20 to 200 mm. It features high repeat accuracy of 0.5 mm and a resolution of less than 0.3 mm, ensuring reliable and accurate readings. The sensor operates with a response and release time of less than 60 ms and has a sonic frequency of 380 kHz. It includes a Teach-in adjustment for easy setup and a target indication flashing for better alignment, along with dual-color LED indicators for operational status. This sensor is equipped with a voltage output of 0 to 10 V or 10 to 0 V, supporting a maximum output current of 20 mA. It offers robust protection features including short circuit and reverse polarity protection. The compact, rectangular plastic housing measures 10.4 mm in width, 27 mm in height, and 14 mm in depth, and it connects via a flylead connector M8. Suitable for operating temperatures from -10 to +60 °C, it is IP 67 rated, ensuring protection against dust and water ingress. Ideal for a variety of industrial applications requiring precise and reliable distance measurement.
- Scanning range Sd:
- 20 200 mm
- Scanning range close limit Sdc:
- 20 200 mm
- Scanning range far limit Sde:
- 20 200 mm
- Repeat accuracy:
- 0.5 mm
- Resolution:
- < 0.3 mm
- Response time ton:
- < 60 ms
- Release time toff:
- < 60 ms
- Temperature drift:
- > 50 mm < 2 % of distance to target Sde
- Sonic frequency:
- 380 kHz
- Adjustment:
- Teach-in
- Alignment aid:
- Target indication flashing
- Light indicator:
- Yellow LED / red LED
- Voltage supply range +Vs:
- 15 30 VDC
- Current consumption max. (no load):
- 35 mA
- Output circuit:
- Voltage output
- Output signal:
- 0 ... 10 V / 10 ... 0 V
- Output current:
- 20 mA
- Residual ripple:
- < 10 % Vs
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Rectangular
- Housing material:
- Plastic (ASA)
- Width / diameter:
- 10.4 mm
- Height / length:
- 27 mm
- Depth:
- 14 mm
- Connection types:
- Flylead connector M8, L=200 mm
- Operating temperature:
- -10 +60 °C
- Protection class:
- IP 67
