Datasensing BX80A/2P-2H Sensors

The Datasensing BX80A/2P-2H Sensors are designed for precision and reliability in industrial applications. These area sensor receivers feature a controlled height of 70 mm and an operating distance of up to 2 meters, making them ideal for detecting objects with a minimum size of 6mm. The sensors are equipped with a microprocessor-based circuit that allows for sensitivity adjustment, ensuring accurate performance in various environments. Housed in a robust cubic design with a special metallic enclosure, these sensors are built for high-duty use and offer a protection degree of IP67, safeguarding against electrical damages and environmental factors. The sensors operate on a voltage range of 12 to 24 VDC and have a response time of 10ms, with a PNP output type that supports both NO and NC functions. The BX80A/2P-2H Sensors are equipped with LED indicators for easy status monitoring: green for power ON, red for alignment, and yellow for output state. They also feature comprehensive protection mechanisms, including short-circuit protection with auto reset, reverse polarity protection, and impulsive overvoltage protection. With a compact size of 44mm x 120mm x 20mm and a weight range of 260 to 300g, these sensors are easy to install using the M12 plug connection. The active head is made of durable glass, and the housing is constructed from PBT material, ensuring longevity and resistance to harsh conditions. The sensors come with supplied accessories, including two M18x1 nuts, an adjustment key, and a 90 angled bracket, facilitating seamless integration into your system. Approved by CE and cULus, and compliant with EMC compatibility standards IEC 60947-5-2, the Datasensing BX80A/2P-2H Sensors are a reliable choice for your sensing needs, offering exceptional performance and durability in demanding industrial environments.
