The Datasensing FALN/BN-0E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring an axial laser with retroreflective polarized technology, these sensors offer a nominal sensing distance of 20 meters, adjustable to suit various applications. With a robust M18 design, they operate on a 10...30 VDC power supply and are equipped with NPN NO+NC output functions. The sensors boast a high switching frequency of 800Hz and a rapid response time of 625µs, ensuring quick and accurate detection.
Constructed with a durable PBT/PC housing and glass/PC active head material, the FALN/BN-0E sensors are built to withstand harsh environments, offering IP67 protection against dust and water ingress. They are also equipped with comprehensive protection features, including short-circuit, overvoltage, and reverse polarity protection, ensuring long-lasting performance.
The sensors are designed with user-friendly features such as sensitivity adjustment via teach-in, and LED indicators for easy status monitoring. They are compatible with various reflectors, providing flexibility in installation and application. With approvals from CE and cULus, these sensors meet international standards for safety and performance, making them an ideal choice for industrial automation and control systems.
- Nominal sensing distance:
- 20m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 800Hz
- Response time:
- 625µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green power supply/yellow (LightON EG?2)/yellow flashing (LightON 1
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LASER Red (650nm) class1
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- Glass / PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 15°C + 55° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP67
