Datasensing FARW/BP-1E Sensors
Datasensing
$169.42
The Datasensing FARW/BP-1E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an axial BGS with an adjustable sensing range of 35-300 mm, these sensors are equipped with a PNP NO+NC output and a robust M12 metal connector. The complete range of M18 sensors operates on a 10...30 Vdc power supply, offering both axial and radial optics with a flat surface for versatile applications.
These sensors are ideal for detecting transparent objects, thanks to their retro-reflective models with red emission and IP67 protection degree. Available in metallic or plastic housing, they provide sensitivity adjustment for all models, ensuring optimal performance in various environments. The sensors are fully protected against any type of electric damages and are CE and cULus listed for quality assurance.
Key features include a nominal sensing distance of 350mm, a thermal drift of Sr ?10% Sr, and a repeat accuracy of 5%. The sensors have a minimum sensing distance (blind zone) of 35mm and operate on the principle of background suppression. They are designed with a trimmer for sensitivity adjustment and have a switching frequency of 1Khz with a response time of 500µs.
The sensors are equipped with short-circuit protection, reverse polarity protection, and are resistant to external light interference up to 5000lux (incandescent lamp) and 10000lux (sunlight). With a compact design of M18 x 1 /L =79,4mm and a weight of 100g, they are easy to install and maintain. The housing is made of nickel-plated brass with a PC plug, and the active head material is PMMA, ensuring durability and longevity.
Operating efficiently in temperatures ranging from -25°C to +70°C, these sensors are supplied with M18 x 1 nuts and a screwdriver for easy setup. With EMC compatibility to EN 60947-5-2 and resistance to shocks and vibrations as per IEC standards, the Datasensing FARW/BP-1E Sensors are a reliable choice for industrial applications requiring high precision and durability.
- Nominal sensing distance:
- 350mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 35mm
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Pin point Red(660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
