Datasensing HER/CN-4F Sensors
Datasensing
$146.64
The Datasensing HER/CN-4F Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency of 1Khz, ensuring rapid response times of just 500µs. The robust stainless steel housing provides complete protection against electrical damages and is rated IP67 for superior resistance to dust and water ingress.
With a nominal sensing distance of 2 meters, these sensors are equipped with a yellow LED status indicator for easy monitoring. They operate on a supply voltage range of 10 to 30 VDC and feature an NPN NC output type, making them versatile for various applications. The sensors are designed with complete short-circuit and reverse polarity protection, ensuring durability and longevity in demanding environments.
The HER/CN-4F Sensors are engineered to withstand thermal drift of ?10%Sr and maintain repeat accuracy of ?10%, ensuring consistent performance. The optic position is axial, and the sensors are equipped with an LED infrared emission at 880nm, providing reliable detection even in challenging lighting conditions with interference resistance up to 5,000 lux from sunlight.
These sensors are compact and lightweight, with dimensions of M8x0.75/L=49mm and a weight of just 15g. They are constructed with high-quality materials, including a stainless steel AISI 303 housing and PMMA active head material, ensuring durability and resistance to shocks and vibrations as per IEC standards. The sensors come with M8 plug 3-pin connections and are supplied with M8 x 0.75 nuts for easy installation.
Approved with CE certification and EMC compatibility with EN 60947-5-2, the Datasensing HER/CN-4F Sensors are an ideal choice for applications requiring reliable and precise photoelectric sensing solutions.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Notes:
- (EG=2)
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN NC
- Output Function:
- NC
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Dimensions:
- M8x0,75/L=49mm
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Dimensions:
- M8x0,75/L=54mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
