The Datasensing Q50RN/0T-0A Sensors are universal photoelectric sensors designed for high performance and versatility. With a nominal sensing distance of 6 meters and a polarized function principle, these sensors are ideal for a wide range of applications. They feature a relay SPDT NO+NC output type, allowing for both normally open and normally closed operations. The sensors are equipped with dual multifunction output state LEDs, providing clear indication of output status and stability.
These sensors are protected against electrical damages, including short-circuit and reverse polarity protection, ensuring reliable operation. They operate on a wide voltage range of 12...240VDC / 24...240VAC at 50-60Hz, with a no-load supply current of 2.5VA when the relay is on. The response time is a swift 25ms, with a switching frequency of 20Hz.
Constructed with a durable PC/ABS housing and a PMMA active head, the sensors are designed to withstand harsh environments, with an operating temperature range of -20°C to +60°C and an IP67 degree of protection. The compact cubic design measures 50x50x17mm and weighs 200g, making it easy to integrate into various systems. The sensors come with a 2m PVC cable for easy connectivity and include a mounting bracket for convenient installation.
- Nominal sensing distance:
- 6m
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,2m
- Function Principle:
- Polarized
- Optic position:
- Axial
- Output type:
- Relay SPDT NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 20Hz
- Response time:
- 25ms
- Operating Voltage:
- 12...240VDC /24...240VAC/50-60Hz
- No-Load supply current:
- 2,5VA ( relay ON)
- LED indicators:
- Yellow (Output status), Green (stability, powerON)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Dimensions:
- 50X50mm
- Weight:
- 200g
- Housing Material:
- PC/ABS
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Operating temperature:
- - 20°C + 60°C ( UL omologation 0°C 60°C)
- Material:
- PC/ABS
- Diameter/Dimension:
- Cubic
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-64
- Degree of protection:
- IP67
- Supplied Accessories:
- Mounting bracket
- Dimensions:
- 50x50x17mm
- Operating Temperature:
- - 20°C + 60°C (Without freeze)
- Mechanical Protection:
- IP67
