Datasensing QMR8/0P-0AVE80 Sensors

The Datasensing QMR8/0P-0AVE80 Sensor is a high-performance photoelectric sensor designed for precision and reliability. This miniature cubic sensor features a diffuse reflection function with an adjustable sensing distance of up to 1000 mm, making it ideal for long-distance detection tasks. The sensor is equipped with a PNP output type and offers selectable light/dark operation, providing flexibility for various applications. Key features include a trimmer for sensitivity adjustment, ensuring optimal performance even with thermal drift of ?10% Sr. The sensor boasts a repeat accuracy of 5% and a fast switching frequency of 1kHz, with a response time of just 500µs. It operates efficiently within a voltage range of 10 to 30VDC, with a no-load supply current of ?30mA and a load current of ?100mA. The QMR8/0P-0AVE80 is built to withstand challenging environments, with a robust PA66 housing and PMMA active head material, offering IP67 mechanical protection. It is resistant to shocks and vibrations as per IEC standards and can operate in temperatures ranging from -25°C to +70°C. The sensor is equipped with LED indicators for status output and stability, and it includes short-circuit and reverse polarity protection for enhanced safety. With a compact design measuring 31.2x21x13mm, the sensor is easy to install using the 200mm PVC cable and M12 plug connection. It is approved with CE and EMC compatibility, ensuring compliance with industry standards. The Datasensing QMR8/0P-0AVE80 Sensor is the perfect choice for applications requiring reliable and accurate photoelectric sensing.
