Datasensing QX3/A0-1A Sensors
Datasensing
$184.00
The Datasensing QX3/A0-1A Sensors are designed for precision and reliability in various industrial applications. Featuring a photoelectric sensor with a diffuse reflection principle, these sensors offer a nominal sensing distance of 300mm and a repeat accuracy of ? 5%. The axial optic position ensures optimal performance, while the NPN/PNP selectable output provides flexibility in integration. With a fast response time of 666µs and a switching frequency of 750Hz, these sensors are ideal for high-speed operations.
Equipped with two LED indicators, the QX3/A0-1A Sensors provide clear status updates with red indicating output status and green for stability. The sensors are built to withstand challenging environments, offering short-circuit and reverse polarity protection, and are capable of operating in temperatures ranging from -25°C to +70°C. The robust ABS housing and IP65 mechanical protection ensure durability, while the compact cubic design (15x23x40mm) allows for easy installation.
The sensors come with a 2m PVC cable for convenient connectivity and include ST70 mounting brackets and screws for secure installation. With CE approvals and EMC compatibility (EN 60947-5-2), these sensors meet high standards of safety and performance. Whether for detecting objects at long distances or ensuring precision in automated systems, the Datasensing QX3/A0-1A Sensors deliver exceptional performance and reliability.
- Nominal sensing distance:
- 300mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Optic position:
- Axial
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 70g
- Connections:
- 2m PVC cable
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
