Datasensing RXS/00-1B Sensors
Datasensing
$197.47
The Datasensing RXS/00-1B Sensors are designed for precision and versatility, offering a range of models including diffuse reflection, retro-reflective, polarized, through-beam, and background suppression. These sensors boast high performance with a nominal sensing distance of 0.3m and a minimum sensing distance of 0.05m, making them ideal for various applications. The compact design, measuring 26x86.6x61mm, allows for easy installation in tight spaces, while the robust housing material ensures durability with an IP65 protection rating.
Equipped with a multifunctional DECOUT® relay output, these sensors provide flexibility with selectable NPN/PNP and NO/NC output types. The built-in timer function offers delay on, delay off, and one-shot capabilities, with a trimmer for sensitivity adjustment to fine-tune detection. The LED alignment indicator provides 360° visibility, ensuring accurate setup with stable signal and output status indicators.
The RXS/00-1B Sensors are designed to withstand challenging environments, operating within a temperature range of -25°C to +70°C without freezing. They feature short-circuit and reverse polarity protection, ensuring reliable performance. The sensors are compatible with M12 standard plug connections and come with supplied accessories, including an ST81 mounting bracket and screws, for seamless integration into your system. With CE and cULus approvals, these sensors meet high safety and quality standards, making them a reliable choice for your sensing needs.
- Nominal sensing distance:
- 0,3m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,05m
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 200 x 200mm EG=1,5
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable Decout NO/NC Selectable
- Output Function:
- Decout NO/NC Selectable
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 40mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- ? 5000lux (incandescent lamp)
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
