Datasensing UK6A/H1-0EUL Sensors
Datasensing
$220.05
The Datasensing UK6A/H1-0EUL Sensors are advanced M18 diffuse reflection sensors designed for precision and reliability. With a nominal sensing distance of 300mm and a thermal drift of Sr ?2%, these sensors ensure accurate performance in various applications. The short housing design incorporates both digital and analogue outputs, with an output type of 0...10V, making them versatile for different systems.
Key features include a beam angle of 7° ± 2°, a resolution of ?2mm, and a repeat accuracy of 0.50%. The sensors are equipped with a teach-in button for easy sensitivity adjustment and have a hysteresis of 1%. They are thermally compensated, ensuring consistent performance across a wide operating temperature range of -20°C to +70°C.
The sensors boast a high switching frequency of 8Hz and a response time of 500ms, making them suitable for dynamic environments. They operate on a voltage range of 10 - 30Vdc, with a no-load supply current of ?35mA at 30V. The robust PBT housing provides IP67 protection, ensuring durability in harsh conditions.
Additional features include short-circuit, reverse polarity, and impulsive overvoltage protection, along with LED indicators for echo and output status. The sensors come with M12 plug connections and are supplied with two M18x1 nuts and two Ø 18 washers for easy installation. With CE cULus approvals and EMC compatibility per IEC 60947-5-2, these sensors are a reliable choice for industrial applications.
- Nominal sensing distance:
- 300mm
- Thermal drift of Sr:
- ?2%
- Repeat Accuracy:
- 0,50%
- Beam angle:
- 7° ± 2°
- Resolution:
- ?2mm
- Sensitivity adjustment:
- Teach-in button
- Hysteresis:
- 1%
- thermal compensation:
- Yes
- Minimum sensing distance (blind zone):
- 40mm
- Linearity error:
- 1%
- Function Principle:
- Diffuse reflection
- Output type:
- 0...10V
- Switching frequency:
- 8Hz
- Response time:
- 500ms
- Operating Voltage:
- 10 - 30Vdc
- No-Load supply current:
- ?35mA @Val = 30V
- Load current:
- 100mA
- Leakage current:
- 10?A @ 30Vcc
- Output voltage drop:
- 2,2Vmax. @ IL=100 mA
- Max ripple content:
- 5%
- LED indicators:
- green: echo - yellow: output
- Time delay before availability:
- ?300ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Minimum load resistence:
- 3k?
- Weight:
- 65g
- Housing Material:
- PBT housing
- Connections:
- M12 Plug
- Tightening torque:
- 1Nm
- Storage temperature:
- - 35°C + 80° C without freeze
- Transducer Frequency:
- 300kHz
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- IEC EN60947-5-2 / 7.4
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M18x1, 2 washers Ø 18
- Mechanical Protection:
- IP67
