LMI Cordsets

Every Gocator sensor has two connectors - one for Power/LAN and the other for I/O. We offer two cordsets for the Power/LAN connection: 1) a dual RJ45 connector cordset for use with a Master hub and a Gigabit Ethernet switch; or 2) a single RJ45 and open-wire cordset for use with a Gigabit Ethernet switch and your own power supply.

The Gocator I/O cordset provides an open-wire end for discrete I/O (2 inputs, 1 output), a quadrature encoder, 1 x serial, and 1 x analog outputs. Cordsets are available with straight or right angle Binder connectors that connect with the sensor.

Standard cordsets:

• 25m I/O cordset, open wire end
• 25m Power and Ethernet cordset, 1x open wire end, 1x RJ45 end
• 25m Power and Ethernet to Master cordset, 2x RJ45 ends

High flex cordsets have a much smaller dynamic bending radius and are intended for use in applications that require frequent sensor movement in tight spaces, for example sensors mounted on robot arms or integrated within larger inspection systems. The cables are rated for a minimum of 2 Million 90° Tick Tock bends and 7 Million U-shaped bends, both at 40mm radius.

High Flex cordsets:

• 2m, 5m, 10m, 15m, 20m I/O cordset, open wire end
• 2m, 5m, 10m, 15m, 20m Power and Ethernet cordset, 1x open wire end, 1x RJ45 end
• 2m, 5m, 10m, 15m, 20m Power and Ethernet to Master cordset, 2x RJ45 ends
