Schneider Electric EGB14045 Miniature Circuit Breaker 277V 45A

Schneider Electric EGB14045 Miniature Circuit Breaker 277V 45A

Schneider Electric
SKU:
EGB14045
|
UPC:
7.85901E+11
Availability:
Contact us to confirm availability and lead times.
$382.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 45A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Additional Information
Height:
5.66 in
Module Type:
E-Frame
Net Weight:
2 lb(US)
Ambient Air Temperature For Operation:
40 °C
[Ue] Rated Operational Voltage:
277 V AC
Width:
0.98 in
Number Of Spaces:
1
Breaking Capacity Code:
G
Line Rated Current:
45 A
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Protection Type:
short-circuit || overload
Product Certifications:
cULus
Breaking Capacity:
35 kA 277 V AC || 35 kA 240 V AC || 65 kA 120 V AC || 35 kA 120/240 V AC
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Electrical Connection:
lugs aluminium
Trip Unit Rating:
1800-1800 A
Circuit Breaker Application:
HACR rated || HID rated
Trip Unit Technology:
thermal-magnetic
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Range Of Product:
125 A Frame EDB-EGB-EJB
Number Of Poles:
1
Mercury Free:
Yes
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Product Destination:
NF panelboard
Mounting Mode:
bolt-on
Holding Current:
630 A
Product Or Component Type:
miniature circuit-breaker
Number Of Spaces Required:
1
Warranty:
18 months
Local Signalling:
trip indicator
Device Short Name:
EGB
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Rohs Exemption Information:
Yes
Depth:
4.05 in
