Schneider Electric HDL36100U53X Circuit breaker, PowerPacT H, 100A, 3 pole, 600VAC, 14kA, lugs, Micrologic 5.2E, 80%

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric HDL36100U53X Circuit breaker, PowerPacT H, 100A, 3 pole, 600VAC, 14kA, lugs, Micrologic 5.2E, 80%

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

HDL36100U53X

UPC:

MPN:

HDL36100U53X

Condition:

New

Electrical Connection:

lugs, line || lugs, load

Awg Gauge:

AWG 14...AWG 3/0 aluminium/copper terminal

Terminal Identifier:

AL150HD

Product Certifications:

UL || CSA || NOM

Mounting Support:

lug

Ambient Air Temperature For Operation:

-25-70°C

Depth:

86 mm

Net Weight:

2.2 kg

Product Or Component Type:

circuit breaker

[Ue] Rated Operational Voltage:

690 V AC 50/60 Hz IEC 60947-3

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Pollution Degree:

3 IEC 60947-1

Device Application:

distribution

Breaking Capacity:

25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC

Breaking Capacity Code:

D

Trip Unit Name:

MicroLogic 5.2 E

Eu Rohs Directive:

Compliant

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Ip Degree Of Protection:

front cover IP40 IEC 60529

Trip Unit Technology:

electronic, energy, MicroLogic 5.2 E, LSI

Utilisation Category:

category A

Mounting Mode:

unit mount lug)

Length:

16 mm

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Ambient Air Temperature For Storage:

-50-85°C

Product Name:

PowerPact H

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Suitability For Isolation:

yes IEC 60947-2

Tightening Torque:

5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)

Mercury Free:

Yes

Line Rated Current:

100-100 A

Circularity Profile:

ENVEOLI1311007EN_V2

Continuous Current Rating:

0.8

Wire Stripping Length:

16 mm

Quantity Per Set:

1

Sustainable Offer Status:

Green Premium product

Country of Origin:

United States

Quality Labels:

CE

Warranty:

18 months

Pvc Free:

Yes

Control Type:

toggle

Environmental Disclosure:

ENVPEP1311007EN

Weight:

2.2 kg

Network Frequency:

50/60 Hz

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Poles Description:

3P
