Schneider Electric JGL26175 Circuit breaker, PowerPacT J, 175A, 2 pole, 600VAC, 18kA, lugs, thermal magnetic, 80%

Schneider Electric JGL26175 Circuit breaker, PowerPacT J, 175A, 2 pole, 600VAC, 18kA, lugs, thermal magnetic, 80%

Schneider Electric
SKU:
JGL26175
$3,212.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT J, 175A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Circularity Profile:
ENVEOLI2206031EN
Weight:
2.4 kg
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Suitability For Isolation:
yes IEC 60947-2
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Net Weight:
2.4 kg
Tightening Torque:
25-25 N.m 25-95 mm² (AWG 4...AWG 4/0)
Country of Origin:
United States
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Product Certifications:
UL || CSA || NOM
Control Type:
toggle
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Device Application:
distribution
Mounting Mode:
unit mount lug)
Pvc Free:
Yes
Sustainable Offer Status:
Green Premium product
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Mercury Free:
Yes
Utilisation Category:
category A
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Circuit Breaker Application:
HACR rated
Rohs Exemption Information:
Yes
Width:
104 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Terminal Identifier:
AL175JD
Magnetic Hold Current:
875 A
Ip Degree Of Protection:
front cover IP40
Poles Description:
2P
Range:
PowerPact
Wire Stripping Length:
25 mm
Warranty:
18 months
Length:
25 mm
Depth:
86 mm
Breaking Capacity Code:
G
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz IEC 60947-3
Pollution Degree:
3 IEC 60947-1
Quality Labels:
CE
Trip Unit Technology:
thermal-magnetic
Environmental Disclosure:
ENVPEP2206031EN
Mounting Support:
lug
Continuous Current Rating:
0.8
Ambient Air Temperature For Operation:
-25-70°C
Product Or Component Type:
circuit breaker
Eu Rohs Directive:
Compliant with Exemptions
Protection Type:
overload protection || short-circuit protection
Height:
191 mm
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Awg Gauge:
AWG 4...AWG 4/0 aluminium/copper terminal
Communication Interface:
Modbus || Ethernet
